| Compatible Models | |
Crawler bulldozer | D8T, D8R |
| Product Specifications | |
| Chassis | GD |
| Axial spacing of mounting bolts (mm) | 410.06 |
| Outer Flange Diameter (mm) | 275 |
| Link Outer Spacing (mm) | 233 |
| Application | Standard Application |
| Flange diameter (mm) | 275 |
| Internal spacing (mm) | 99 |
| Shaft Outer Diameter (mm) | 58 |
| Mounting cover bolt thread size | M24 |
| Mounting width (mm) | 306.74 |
| Mounting cover bolt bore (mm) | 24.5 |
| Shaft Length (mm) | 456.56 |
| Lateral spacing of mounting bolts (mm) | 90 |
| Compatible with Carrier Wheels | Yes |
| Flange Type | Single Flange |
| Tread diameter (mm) | 247 |
